Commercial Pressure Gauges

Our product range includes Non - Ferrous Pressure Gauge, Stainless Steel Pressure Gauge and Pressed Steel Pressure Gauge.

Stainless Steel Pressure Gauges

Stainless Steel Pressure Gauges

We have established ourselves as a reputed organization that is involved in making Stainless Steel Pressure Gauges.
This stainless steel pressure gauge can be installed on every chemical, petrochemical plants, onshore and offshore applications, machinery, food and pharmaceutical industry. Our offerings are corrosion resistance have wide application in power generation, pollution control equipment, chemical & petrochemicals and oil exploration.

Specifications:

  • Make: Hi-Tech
  • Type: Bourdon
  • Code: SSPG
  • Accuracy: ± 1% of FSD
  • Sensing: SS 316 Diaphragm (Standard)
  • Top Chamber Material: SS 304
  • Bottom Chamber Material: SS 316
  • Connection: 1/2 NPT (M) (Standard)
  • Case & Bezel: Cast Aluminium, Weatherproof, Painted Stove Enamelled Black with screwed inner Bezel of ABS Plastic
  • Glass: Plain
  • Temperature Limit: 270°C
  • Over Range Protection: 125.00%
  • Standard Fitments: Micro Adjustable Pointer & Blow Out Disc

Mounting:
W1: Bottom connection projection mounting
W2: Bottom Connection Direct Mounting
W5: Back Connection Panel Mounting
Request Quote


Non Ferrous Pressure Gauges

Non Ferrous Pressure Gauges

We have come up with Non - Ferrous Pressure Gauges with the help of our dexterous professionals. We offer our valued clients ensure that Non - Ferrous Pressure Gauge are engineered in the purview of our highly qualified team of experts. These are designed to shoulder extensive pressure under most demanding applications.

specifications:
Make: Hi-Tech
Type: Bourdon
Accuracy: ± 1% of FSD
Bourdon Material: Brass
Movement Material: Brass
Socket Material: Brass
Case & Bezel: Cast Aluminum, Weatherproof, Painted Stove Enamelled Black with screwed inner Bezel of ABS Plastic
Connection: 3/8" BSP (M) (Standard)
Glass: Plain
Temperature Limitation: 125°C
Mounting:
W1: Bottom connection projection mounting
W2: Bottom Connection Direct Mounting
W5: Panel Mounting Back Connection

Request Quote

Pressed Steel Pressure Gauges

Pressed Steel Pressure Gauges


We are manufacturers and suppliers of a comprehensive range of high precision and best quality Pressed Steel Pressure Gauges. We have crafted this range precisely using the quality raw material.

The offered range is a pressure reading device for high compressed steel. Customers are offered this range at the most comprehensive and market leading price range.

Following are the specifications of this range:

Type: Boudon
Code: PSPG
Accuracy of +2% of FSD
Bourdon material: Brass
Movement material: brass
Socket material: brass
Connection: 1/8" BSP, 1/4" BSP, 3/8" 1/2" BSP
Case: Pressed steel, painted stove enamelled black
Mounting:
M1: Bottom connection projection mounting
M2: Bottom Connection Direct Mounting
M3: Back Connection Direct Mounting
M5: Glass, plain

Request Quote
